Soilwatersampler
Contact us at equipment@dmr.eu for a quote
Specifications:
- Size: 500.4x293x445.5(mm) – 19.7×11.54×17.54(in)
- Weight empty: No batteries, no sample bottle: 10 Kg – 22.04 lbs.
- Weigth full: 3 x batteries, 2 L. sample bottle: 11.5 Kg – 25.35 lbs.
- Operating temperature: -10°C to 50C. (Above 0C for water in sample tubes.)
- IP rating: IP23 (IP64 with optional hydrophobic air filters).
- Battery type: DeWALT 18V, 1-3 pcs.
- Operating voltage: 16V to 25V.
- Current max: 1.6A @ 22V.
- Estimated operating life: 3 x 5Ah DeWALT batteries, DualTube mode, logging each 60 minutes:
Price is + VAT shipping and customs.
Description
Soilwater Sampler (SWS) is an advanced automatic water sampler for the unsaturated zone in soil.
SWS is designed for unsupervised battery powered long-term sampling and measurements in the
field. SWS will collect soil water samples and send data live for monitoring of sampling progression
to DMR Cloud platform.
This manual will guide the customer using the sampler, how to operate it electronically and
mechanically. How to connect external sensors and change sample bottles during field
measurements.
